Parts

Definition:

800*480

Pels:

2.65million

Type:

Tft(Thin Film Transistor) Active Matrix,Light Penetration

Edge Illume:

Cold Cathode Light

Colors System:

Ntsc/Pal Compatible

Temperature Range:

-10°C~~+50°C Centigrade

Save Temperature Range:

-20°C~~+80°C Centigrade

Touch Screen:

Resistance& Press Simulate(Film+ Glass)

Gps

Manner:

L1,C/A Code Gps Sps Standard Localizer Service

Receive Manner:

12channel

Receive Frequency:

1575.42mhz

Sensitive:

-130dbm

Test Renovate Time:

Once Each Second

General Parameters

Max Consume Current:

10.0a

Pressure:

Dc12v(11v~16v)

Grounding Manner:

Cathode Grounding Manner

External Image Input Level:

1v P-P/75 Ohm

The Max Input Level Of External Sound:

1.5v/22 K-Ohm

Image Output Level:

1v P-P/75 Ohm(White 100% Output /When Displaying Dvd)

Amplifier, Audio Part

The Max Output Of Power :

45 W*4

Load Impedance:

4 Ohm

The Max Output Level /Resistance Prefix:

2.0 V/100 Ohm

Equal Loudness Curve:

6db,(10khz)

Equalizer:

100hz-14~+6db,10khz±10db

Dvd Display Parts

Disk Format Supported:

Dvd-Rom,Dvd-Video, Dvd-R(Video Mode) /Rw (Video Mode),Cd-Rom,Cd-Da,Cd-R/Rw

Zone Number:

6

Signal Format(Sampling Frequency):

(Dvd):48/96 Khz
(Cd):44.1 Khz

Signal Format(Quantum B It):

(Dvd):16/20/24b It Beeline
(Cd):16b It Beeline

Frequency Feature:

(Dvd):8hz ~44khz(± 1db)
(Cd):20hz~20khz(± 0.1/-0.3db)
S/N(Dvd):97db(1khz )
(Ihf-A Network)
(Cd):96db(1khz )
(Ihf-A Network)

Dynamic Bound:

(Dvd):95db(1khz )
(Iec-A Curve/20khz Lpf)
(Cd):94db(1khz)
(Iec-A Curve/20khz Lpf)

Harmonic Distortion Rate:

0.008%(1khz )

Channel :

2(Dimensional Sound)

Fm/ Tune Parts

Receive Frequency Wave Band:

(87.5mhz~108mhz)

Sensitive Degree:

9dbf(0.7µv/75ohm Single Channel S/N30db)

50db Sensitive Degree:

14dbf

S/N:

50dbMore than(Ihf-A Web)

Harmonic Distortion Rate:

0.3%(At 65dbf,1khz,Ster-Eo)
0.1%(At 65dbf,1khz,Mono)

Frequency Feature:

30hz~15000hz(±3db)

Dimensional Sound Distinguish:

45dbMore than(65dbf Input,1khz)

Am/Tune Parts

Receive Frequency Wave Band:

531khz ~1602khz (9khz )
530khz ~1604khz (10khz )

sensitive Degree:

18µv(S/N 20db)

Perform Selection:

65 Db(Ihf-A Network)

Gps Antenna

Antenna:

Microwave Transmission, And Plane Antenna/ Right-Hand Circularly Polarized Wave

Antenna Length :

5.0m

Product Size

Size:

178(W)*100(H)*165 (D)Mm

Gps Antenna Magnetic Base:

39(W)*15.5(H)*48.5 (D)Mm

Total Weight

Weight:

2.5kg
